Using A pplication Modules
Optional application module packages extend the capability of your oscilloscope. (See page 13, Application M odule Free
Trial.) You can install up to two application modules at one time. (See page 14, Installing an Application Module .)
Refer to the MSO/DPO2000B and MSO/DPO2000 Series Oscilloscopes Application Module Installation that came with
your application module for instructions on installing and testing an application module. Some modules are described
in the following list. Additional modules may be a vailable. C ontact your Tektronix representative or visit our Web site
at www.tektronix.com for more information.
The DPO2EMBD Em bedded Serial Triggering and Analysis Module adds triggering on packet level information in
serial buses used in embedded designs (I
2
C and SPI), as well as analytical tools to help you efficiently analyze your
serial bus. T hese include bus views, packet decoding, search tools, and event tables with timestamp information.
The DPO2AUTO Automotive Serial Triggering and Analysis M odule adds triggering on packet level information in
serial buses used in automotive designs (CAN and LIN), as w ell as analytical tools to help you efficiently analyze your
serial bus. T hese include bus views, packet decoding, search tools, and event tables with timestamp information.
The DPO2CO M P Computer Serial Triggering and Analysis Mod ule adds triggering on byte or packet level information
in RS-232, RS-422, RS-485, and UART buses, and analytical tools to help you efficiently analyze your serial bus. These
include bus views, packet decoding, search tools, and event tables with timestamp information.
