Analyze Wavefor
mData
3. Investigate your waveform by moving
from search mark to search m ark. Use
the next ( )or
previous ()arrow
button to jump from one marked location
to another, without adjusting any other
controls.
4. Deleteamar
k. Push the next ( )or
previous () arrow button to jump to the
mark you want to clear. To remove the
current, ce
nter-positioned mark, push
Set/Clear. It works on both manually
and automatically created marks.
To automatically set and clear (delete) search marks:
1. Push Sear
ch.
2. Push the Search lower bezel menu and
select O
n.
The search menu is similar to the trigger
menu.
Search
On|Off
Save All
Marks
Clear A
ll
Marks
Copy
Search
Setti
ngs to
Trigger
Copy
Trigger
Setti
ngs to
Search
3. Push
Search Type.
Search
On
Search
Type
Edg
e
Source
1
Slope
Threshold
0.0
0V
108 MSO2000B and DPO2000B Series Oscilloscopes User Manual
