Analyze Wavefor
mData
Search Description
Rise/Fall Tim
e
Search for ris
ing and/or falling edges that are >, <, =, or a user specified time.
Bus
Parallel: S e a
rch for a binary o r hex value (MSO2000B series only).
I
2
C: Search for Start, Repeated Start, Stop, Missing Ack, Address, Data, or Address and
Data.
SPI: Search f
or SS Active, MOSI, MISO, or MOSI & MISO
CAN: Search for Start of Frame, Type of Frame (Data, Remote, Error, Overload), Identifier
(standard or extended), Data, Identifier and Data, End of Frame, Missing Ack, or Bit Stuffing
Error
RS-232, RS-422, RS-485, UART: Search for Tx Start Bit, Rx Start Bit, Tx End of Packet, Rx
End of Packet, Tx Data, Rx Data, Tx Parity Error, or Rx Parity Error.
LIN: Searc
h for Synch, Identifier, Data, ID & Data, Wakeup Frame, Sleep Frame, or Error
110 MSO2000B and DPO2000B Series O scilloscopes User Manual
