Acquire the Signal
Push Bit Rate, and turn multipurpose knob a to
select the appropriate bit rate.
Bit Rate
2400 bps
Push LIN Standard, and turn multipurpose
knob a to select the appropriate stan dard.
LIN
Standard
v1.x
Push Include Parity Bits with Id to select
whether or not to include parity bits.
Include
Parity Bits
with Id
Yes
No
DPO3000 Series Oscilloscopes User Manua l 101
