Application E xamp les
6. Select Odd Fields.
Odd Fields
If the signal had been n oninterla ced, you could
choose to trigger on All Fields.
7. Turn the Ho rizontal Scale knob to see a
complete field across the screen.
8. View results.
252 DPO3000 Series Oscilloscopes User Ma nual
