Tektronix DPO3000 Series User Manual

Application Examples
Triggering on Lines
Triggering on Lines. To loo k at the video lines in the field:
1. Push Trigger Menu.
2. Push Type.
Type
3. Turn multipurpose knob a to scroll th rough the
trigger type side menu until you select Video.
Video
DPO3000 Series Oscilloscopes User Manua l 253
