Tektronix DPO3000 Series User Manual

Application E xamp les
Type
Video
Video
Standard
525/NTSC
Source
1
Trigger On
All Lines
Mode
Auto
& Holdoff
4. Push Trigger On.
5. Select All Lines.
To trigger on a speci fi c line, select Line
Number, and use multipurpose knob a to
select the line number.
All Lines
6. Adjust Horizontal Scale to see a complete
video line across the screen.
254 DPO3000 Series Oscilloscopes User Ma nual
