Installation
Change
Instrument
Settings
DHCP/
BOOTP
On|Off
7. To use Ethernet, push Ethernet Network
Settings.
On the side-bezel menu, if you are on a DHCP
Ethernet network and using a through cable,
set DHCP to On. If you are using a cross-over
cable, set it to Off and set a hard coded TCPIP
address.
Test
Connection
8. If you are using GPIB, push GPIB.Enterthe
GPIB address on the side-beze l men u, using
multipurpose knob a.
Talk/Listen
Address
(a) 1
This will set the GPIB address on an attached
TEK-USB-488 Adapter.
DPO3000 Series Oscilloscopes User Manua l 43
