Offset accuracy, >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch3 140 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0525 V
–16.5 mV
+5.9475 V
__________
__________
__________
__________
__________
__________
–5.9475 V
+16.5 mV
+6.0525 V
Ch3 200 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0585 V
–22.5 mV
+5.9415 V
__________
__________
__________
__________
__________
__________
–5.9415 V
+22.5 mV
+6.0585 V
Ch3 400 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0785 V
–42.5 mV
+5.9215 V
__________
__________
__________
__________
__________
__________
–5.9215 V
+42.5 mV
+6.0785 V
Ch4 6.25 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–3.13 mV
+3.3831 V
–3.4169 V
__________
__________
__________
__________
__________
__________
+3.125 mV
+3.4169 V
–3.3831 V
Ch4 10 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–3.5 mV
+3.3827 V
–3.4173 V
__________
__________
__________
__________
__________
__________
+3.5 mV
+3.4173 V
–3.3827 V
Ch4 20 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–4.5 mV
+3.3817 V
–3.4183 V
__________
__________
__________
__________
__________
__________
+4.5 mV
+3.4183 V
–3.3817 V
Ch4 50 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–7.5 mV
+3.3787 V
–3.4213 V
__________
__________
__________
__________
__________
__________
+7.5 mV
+3.4213 V
–3.3787 V
Ch4 100 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–12.5 mV
+3.3737 V
–3.4263 V
__________
__________
__________
__________
__________
__________
+12.5 mV
+3.4263 V
–3.3737 V
Ch4 120 mV Vert scale, 0 Div position setting,
0 V offset, 0 V termination
+3.4 V offset, +3.5 V termination
-3.4 V offset, -3.5 V termination
–14.5 mV
+3.3717 V
–3.4283 V
__________
__________
__________
__________
__________
__________
+14.5 mV
+3.4283 V
–3.3717 V
Ch4 140 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0525 V
–16.5 mV
+5.9475 V
__________
__________
__________
__________
__________
__________
–5.9475 V
+16.5 mV
+6.0525 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
164 MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
