Tektronix DPO5000 Series Technical Reference

Offset accuracy, >20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch4 200 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0585 V
–22.5 mV
+5.9415 V
__________
__________
__________
__________
__________
__________
–5.9415 V
+22.5 mV
+6.0585 V
Ch4 400 mV Vert scale, 0 Div position setting,
-6 V offset, 0 V termination
0 V offset, 0 V termination
+6 V offset, 0 V termination
–6.0785 V
–42.5 mV
+5.9215 V
__________
__________
__________
__________
__________
__________
–5.9215 V
+42.5 mV
+6.0785 V
Offset accuracy, ≥4 GHz, ≤20 GHz models
Instrument performance test Minimum Incoming Outgoing Maximum
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
5 Div position setting, -0.45 V offset
+ 495.75 mV
- 504.25 mV
__________
__________
__________
__________
+ 504.25 mV
- 495.75 mV
Ch1 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
5 Div position setting, -0.4 V offset
+ 494.75 mV
- 505.25 mV
__________
__________
__________
__________
+ 505.25 mV
- 494.75 mV
Ch1 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
5 Div position setting, -0.25 V offset
+ 491.75 mV
- 508.25 mV
__________
__________
__________
__________
+ 508.25 mV
- 491.75 mV
Ch1 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
5 Div position setting, -2.0 V offset
+ 2.474 V
- 2.526 V
__________
__________
__________
__________
+ 2.526 V
- 2.474 V
Ch1 200 mV Vert scale setting,
-5 Div position setting, +1.5 V offset
5 Div position setting, -1.5 V offset
+ 2.464 V
- 2.536 V
__________
__________
__________
__________
+ 2.536 V
- 2.464 V
Ch1 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
5 Div position setting, 0 V offset
+ 2.434 V
- 2.566 V
__________
__________
__________
__________
+ 2.566 V
- 2.434 V
Ch2 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
5 Div position setting, -0.45 V offset
+ 495.75 mV
- 504.25 mV
__________
__________
__________
__________
+ 504.25 mV
- 495.75 mV
Ch2 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
5 Div position setting, -0.4 V offset
+ 494.75 mV
- 505.25 mV
__________
__________
__________
__________
+ 505.25 mV
- 494.75 mV
Ch2 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
5 Div position setting, -0.25 V offset
+ 491.75 mV
- 508.25 mV
__________
__________
__________
__________
+ 508.25 mV
- 491.75 mV
Ch2 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
5 Div position setting, -2.0 V offset
+ 2.474 V
- 2.526 V
__________
__________
__________
__________
+ 2.526 V
- 2.474 V
Ch2 200 mV Vert scale setting,
-5 Div position setting, +1.5 V offset
5 Div position setting, -1.5 V offset
+ 2.464 V
- 2.536 V
__________
__________
__________
__________
+ 2.536 V
- 2.464 V
Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series 165
