Replaceable Parts (MSO70000/C, DSA/DPO70000C Series)

Table 5-24: Rep

laceable parts – μATX 1 (MSO70000/C, DSA/DPO70000C Series)

Fig. &

index

number

Tektronix

part

number

Serial no.

effective

Serial no.

discont’d Qty Name & description

5-26- μATX 1

-1 174-5629-00 1

CABLE, LVDS VIDEO WITH 2X20 HIROSE CONNECTORS;PCIe J18

to μATX LVDS1

-2 174-5763-00 1

CABLE, SATA TO E-SATA, DATA ONLY; RP e-SATA to μATX SATA 2

-3 441-2585-00 1

BRACKET, IO M-BOARD, AMB566, SAFETY CONTROLLED

**ATTACHING PARTS**

211-1050-00 10

SCREW, MACHINE; 6-32 X 0.312 L, PNH, STEEL, ZINC FINISH, T15

214-3903-01 6

SCREW, JACK; 4-40 X 0.312 EXT THD, 4-40 INT THD, 0.188 HEX, ZINC

PLATED STEEL

**END ATTACHING PARTS**

5–50 MSO70000/C, DSA70000B/C, DPO70000B/C, DPO7000, MSO5000, DPO5000 Series
