Offset
Current
Generator
This
circuit
consists
of
amplifier
U1631
;
field
-
effect
tran
sistors
Q1522
and
Q1532
;
transistors
Q1521
,
Q1611
,
Q1531
,
and
Q1621
;
plus
related
components
.
Voltage
from
the
DAC
is
applied
to
the
inverting
input
of
U1631
,
which
has
a
voltage
gain
of
one
.
Q1522
and
Q1532
are
part
of
a
double
-
ended
current
path
that
begins
at
the
26
V
supply
,
through
L1721
,
R1621
,
R1602
,
CR1512
,
etc.
,
through
to
the
+26
V
supply
.
By
controlling
the
voltage
on
the
gate
of
Q1522
,
the
current
through
the
series
string
is
similarly
controlled
.
Potentiom
eter
R1601
sets
the
gain
for
the
positive
offset
generator
;
R1602
sets
the
gain
for
the
negative
offset
generator
.
Since
both
offset
generators
cannot
be
on
at
once
,
tran
sistor
current
switches
Q1521
-
Q1611
and
Q1531
-
Q1621
di
vert
current
away
from
one
or
the
other
generator
to
prevent
simultaneous
operation
.
If
positive
offset
is
select
ed
,
a
is
selected
at
U1521
pin
7
,
and
1
at
pin
6.
This
cuts
off
Q1521
and
Q1611
,
which
permits
current
to
flow
INTRODUCTION
These
three
diagrams
depict
functions
that
are
ancillary
to
the
signal
-
generating
loop
of
the
FG
5010.
Block
-
level
discussions
of
these
circuits
are
found
elsewhere
in
the
description
,
as
follows
:
Trigger
Circuits
:
Phase
Lock
Circuits
:
N
Burst
Circuits
:
Refer
to
the
Loop
2
Block
Diagram
Description
.
Refer
to
the
Loop
2
Block
Diagram
Description
.
Refer
to
the
Sine
Shaper
Block
Diagram
Description
.
15
TRIGGER
SECTION
Theory
of
Operation
-
FG
5010
TRIGGER
,
PHASE
LOCK
,
AND
N
BURST
CIRCUITS
Introduction
The
Trigger
Section
receives
the
signal
from
the
front
panel
TRIG
/
GATE
IN
connector
,
processes
it
,
and
sends
the
processed
signal
to
the
Loop
1
circuits
,
and
elsewhere
in
the
Loop
2
circuits
.
The
section
also
conveys
triggering
status
through
the
upper
half
of
the
offset
string
.
The
1
at
U1542
pin
6
causes
Q1531
and
Q1621
to
conduct
,
diverting
the
current
away
from
the
lower
part
of
the
string
.
Thus
,
the
Positive
generator
furnishes
offset
current
in
this
example
,
and
the
Negative
Generator
does
not
.
Positive
Offset
Generator
This
circuit
consists
of
amplifier
U1611
,
transistor
Q1601
,
and
related
components
.
This
circuit
operates
much
like
a
conventional
current
regulation
circuit
.
As
mentioned
earlier
,
R1601
sets
the
gain
.
As
current
through
R1601
is
changed
by
changing
the
offset
requirements
,
U1611
and
U1601
respond
by
increasing
or
decreasing
the
current
through
the
output
network
.
Negative
Offset
Generator
This
circuit
consists
of
amplifier
U1621
,
transistor
Q1501
,
and
related
components
.
Other
than
the
polarity
of
the
output
current
,
the
circuit
is
the
same
as
the
Positive
Offset
generator
.
Refer
to
that
description
for
more
details
.
to
the
CPU
,
and
selects
the
trigger
slope
.
The
section
con
sists
of
the
Trig
-
Gate
Input
Amplifier
,
the
Trig
-
Gate
Slope
Selector
,
and
the
Trigger
Status
Sensor
.
Trig
-
Gate
Input
Amplifier
This
circuit
consists
of
matched
field
-
effect
transistors
Q1020
and
Q1022
;
transistors
Q1032
,
Q1030
,
Q1036
,
Q1034
;
buffers
U1212A
and
U1212F
;
plus
related
circuitry
.
The
trigger
or
gate
signal
is
applied
through
front
-
panel
con
nector
J1650
to
the
input
compensation
network
,
which
is
1
MS
impedance
or
50
£
impedance
,
depending
on
the
con
nection
of
P1030
.
From
the
network
,
the
signal
is
fed
to
the
gate
of
FET
Q1020
,
which
with
Q1022
form
a
high
-
imped
ance
unity
-
gain
buffer
.
Diodes
CR1021
and
CR1020
protect
the
input
from
large
voltage
transients
.
Zener
diodes
VR1024
and
VR1023
reduce
the
power
dissipation
across
Q1020
and
Q1022
.
The
signal
is
taken
from
the
source
of
Q1020
and
applied
to
the
base
of
Q1032
,
part
of
the
input
differential
pair
of
a
Schmitt
trigger
circuit
.
Transistors
Q1032
and
Q1030
form
a
differential
pair
that
switches
the
current
from
R1031
.
This
differential
pair
drives
a
second
pair
,
Q1034
and
Q1036
.
Through
R1029
,
positive
feedback
4-35
