7
П
П
П
7
n
П
П
П
П
П
П
П
C
C
is
tested
for
a
low
,
causing
Error
324
if
it
is
high
.
Next
,
the
loop
cycle
counter
is
clocked
again
by
setting
U1340
pin
9
high
.
This
should
clock
the
loop
cycle
counter
from
1
to
,
causing
the
terminal
count
gate
U1230
pin
6
to
go
high
,
and
reset
U1220A
through
gate
U1222A
.
U1220
pin
13
is
tested
for
a
high
,
and
Error
324
is
displayed
if
it is
low
.
U1220B
should
reset
when
it
is
clocked
,
by
setting
U1340
pin
9
low
.
U1220
pin
8
is
tested
for
a
high
,
causing
Error
323
if
it
is
low
.
During
the
time
that
U1220B
was
set
,
the
reference
fre
quency
counters
(
U1320
and
U1322
)
should
count
the
4
MHz
reference
clock
.
The
reference
count
is
read
through
shift
registers
U1330
and
U1332
and
tested
for
a
count
of
453E
to
4544
Hex
;
Error
322
is
displayed
if
it is
incorrect
.
Then
,
the
reference
frequency
counters
are
reset
by
setting
U1212
pin
3
low
.
U1212
pin
3
is
set
high
,
and
U1220B
is
set
by
toggling
U1340
pin
9.
The
MPU
waits
20
ms
for
the
refer
ence
frequency
counters
to
overflow
;
the
overflow
bit
(
U1322
pin
12
)
is
tested
for
a
high
,
and
Error
323
is
dis
played
if
it
is
low
.
This
completes
the
frequency
control
logic
test
on
the
Loop
2
board
.
Errors
325
,
327
,
328
,
329
,
330
,
331
,
332.
The
Loop
1
board
is
tested
by
using
the
frequency
control
logic
on
the
Loop
2
board
.
The
reference
and
loop
cycle
counters
are
used
as
a
frequency
counter
.
Loop
1
is
set
for
the
continu
ous
mode
on
the
2
MHz
frequency
range
.
The
frequency
DAC
(
digital
to
analog
converter
,
U1612
)
is
set
to
a
maxi
mum
count
of
4095.
The
frequency
generated
by
Loop
1
is
measured
by
Loop
2
and
tested
to
see
if
it
is
between
1.6
MHz
and
4.0
MHz
.
Error
327
is
displayed
if
this
test
fails
.
The
frequency
prescaler
(
U1232
,
Loop
2
)
is
set
to
di
vide
by
10
,
and
the
frequency
is
measured
again
.
If
the
prescaled
output
is
not
between
160
kHz
and
320
kHz
Error
325
is
displayed
.
Each
frequency
range
is
tested
for
a
top
end
frequency
between
2
and
4
;
i.e.
,
the
2
kHz
range
is
tested
for
a
frequency
between
2
kHz
and
4
kHz
.
Each
of
these
frequency
range
tests
is
performed
at
10
,
50
,
and
90
REV
JAN
1982
Maintenance
-
FG
5010
percent
symmetry
settings
.
Errors
328
,
329
,
330
,
331
,
and
332
correspond
to
ranges
2
kHz
,
20
kHz
,
200
kHz
,
2
MHz
,
and
20
MHz
.
Error
326.
With
the
Loop
1
board
set
for
20
MHz
,
the
low
frequency
generator
is
tested
by
measuring
the
frequency
of
the
low
frequency
square
signal
(
U1210
pin
13
,
Loop
2
)
.
The
loop
cycle
counter
is
set
for
a
count
of
one
cycle
.
The
clock
multiplexer
for
the
loop
cycle
counter
(
U1222B
,
Loop
2
)
is
set
to
select
the
LFSQ
signal
.
The
frequency
is
measured
and
Error
326
is
displayed
if
it is
not
between
200
Hz
and
400
Hz
.
Error
333.
The
next
test
performed
is
on
the
burst
counter
on
the
Sine
Shaper
board
.
For
this
test
,
the
Loop
1
board
is
set
to
2
MHz
and
placed
in
the
burst
mode
.
The
loop
cycle
counter
counts
the
exact
number
of
cycles
in
the
burst
.
The
loop
cycle
counter
(
U1130
,
U1132
,
U1110
,
and
U1120
,
Loop
2
)
is
preset
to
a
count
of
9999
cycles
.
Then
the
burst
count
is
set
for
9999
cycles
.
The
frequency
prescaler
(
U1232
,
Loop
2
)
is
set
to
divide
by
1
,
and
the
duty
cycle
control
bit
(
U1340
pin
9
,
Loop
2
)
is
set
high
.
The
loop
cycle
counter
is
enabled
to
count
by
setting
U1212
pin
3
,
Loop
2
high
.
The
MPU
triggers
the
burst
using
the
manual
!
trigger
signal
.
When
the
burst
is
completed
the
HFSQ
signal
from
Loop
1
(
U1232
pin
14
,
Loop
2
)
should
be
high
.
The
loop
cycle
counter
counted
down
from
9999
to
,
causing
the
terminal
count
signal
(
U1230
pin
6
,
Loop
2
)
to
go
high
.
The
next
high
to
low
transition
of
HFSQ
clocks
U1220B
,
Loop
2
,
indicating
measurement
completed
.
U1220
pin
8
,
Loop
2
is
tested
for
a
low
,
causing
Error
333
if
it
is
high
.
This
indicates
that
the
burst
was
longer
than
9999
cycles
.
Then
,
the
duty
cycle
control
bit
(
U1340
pin
9
,
Loop
2
)
is
set
low
,
causing
U1220B
to
clock
from
the
set
to
the
reset
state
.
If
the
burst
was
shorter
than
9999
cycles
,
the
terminal
count
signal
(
U1230
pin
6
)
will
not
be
high
,
and
U1220B
will
not
reset
.
U1220
pin
8
,
Loop
2
is
tested
for
a
high
,
causing
Error
333
if
it
is
low
.
This
test
fails
if
the
manual
trigger
function
does
not
work
.
7-13
