INST
ID
2
3
4
Causes
the
FG 5010 to
display
its bus
address
and
generate a service request ( SRQ ) over the GPIB .
FUNCTION
The buttons in this group are illuminated when the
associated
function is
active
.
These
functions
, ex
cept
HOLD , are
mutually
exclusive .
SQUARE
(
2
)
HOLD
TRIANGLE
( ~ )
SINE
(
) -
Sinusoidal
waveforms
will be
gen
erated
at
the
output
connector .
TRIG
GATE
MODE
The buttons in this group are illuminated when the
associated
mode
is
active
.
These functions are mu
tually
exclusive
.
CONT
BURST
-
Square
waveforms will be
gener
ated at the output connector .
PH
LOCK
-
Triangle
waveforms will be
gener
ated at the
output
connector
.
REV JUL 1982
- The
output
waveform
( below
200 Hz ) is held at its instantaneous
level .
-
The
waveform , at
the
programmed
frequency
, is
continuously
generated .
- One complete cycle of the selected
waveform will be generated for each
trigger
signal at
the
TRIG /
GATE IN
connector or each time the MAN but
ton
is
pressed .
-
The
selected
waveform
is
generat
ed
continuously
for
the
duration of
the gating signal at the TRIG / GATE
IN
connector or for
as long as
the
MAN button is
held in .
- A pre - programmed number of cy
cles
of
the
selected
waveform is
gen
erated for
each
trigger or
gate signal
at the TRIG / GATE IN connector or
each time the MAN button
is
pressed
.
-
The
waveform
generated
is
phase
locked to
the
input
trigger
signal .
PARAMETER
The buttons in this group are illuminated when the
associated parameter is selected . These functions
are
mutually
exclusive
.
FREQ
- Allows the
operator
, via
the key
board , to set or observe the frequen
cy
of
the output
waveform
.
5
6
AMPL
OFFSET
SYM
PHASE
N BURST
Operating
Instructions -
FG 5010
-
Allows the
operator
,
via the
key
board
, to
set or
observe
the
ampli
tude of the output waveform .
-
Allows the
operator
,
via the
key
board , to set or observe the dc offset
voltage .
-
Allows the
operator , via
the key
board
, to
adjust
or
observe
the
sym
metry of the
output
waveform
.
-
Allows the
operator , via
the
key
board , to set or observe the baseline
of the output
waveform
, with
respect
to
a
ramp - up
zero - crossing
of the
tri
angle
, for TRIG
,
GATE , and
BURST
modes .
Also
allows
the
operator , via
the keyboard , to set the phase rela
tionship
of
the
trigger
trigger output
waveform
relative to
the
input
trigger
signal
for PH LOCK
mode .
Allows
the
operator
, via
the key
board , to set or observe the number
of cycles that will be generated when
operating
in the
BURST
mode
.
INCR SIZE -
Allows the
operator
,
via the key
board , to set or observe the size of
the increment / decrement step for the
parameter selected . If no value is set ,
the step size will default to the least
significant digit ( LSD ) displayed . Key
board zero ( ) is used to return the
step
size
back to
LSD .
INCREMENT
These
two
buttons
incrementally
vary
the
param
eter up ( 1 ) or down ( ↓ ) . When the button is pressed
and
released , the
parameter will be
stepped
one
unit of the defined increment size . When the button
is in the
HOLD
FOR
AUTO
( press
and hold )
posi
tion , the parameter will be stepped in units of the
defined
increment
size
, but will
accelerate
to
a rap
id rate , until
the
button is
released or the
parameter
limit is
reached
.
NUMERIC KEYBOARD
These fifteen non - illuminated keys are used to es
tablish
the
numerical
value of the
selected
param
eter and associated exponent . The function of the
0-9 keys should be self - explanatory . The other four
keys
are briefly
described
below
.
EEX
- Followed by the +/- key and one
or more digits , sets the exponent to
be
applied
to
the numerical
value of
the
selected
parameter .
2-3
