7
n
7
П
П
П
C
Down
Shrink
Current
Source
This
circuit
is
also
a
voltage
to
current
converter
that
provides
the
Down
Shrink
Current
for
the
Level
Detector
.
The
stage
consists
of
amplifier
U1641D
,
Darlington
transis
tor
Q1551
,
transistor
Q1242
,
and
related
components
.
Bias
for
Q1242
is
provided
by
VR1351
,
depicted
on
Diagram
12
.
This
sets
the
base
of
Q1242
at
approximately
-5.8
V.
The
voltage
from
U1641C
is
applied
to
R1652
and
alge
braically
summed
with
the
+10
V
reference
.
The
difference
drives
U1641D
,
which
in
turn
drives
Q1551
and
Q1242
.
The
cascode
configuration
decouples
the
transitions
from
the
Level
Detector
from
affecting
the
performance
of
this
stage
.
Relay
Drivers
Relays
K1131
through
K1331
are
driven
by
buffers
U1311
through
U1411
.
These
drivers
are
Darlington
pairs
,
one
pair
to
each
driver
.
Each
is
in
turn
driven
by
a
line
from
one
of
the
latches
.
The
purpose
of
each
relay
is
stated
in
Table
4-1
.
K1131A
K1131B
K1231A
K1231B
K1321A
K1321B
K1322A
K1322B
K1323A
K1323B
K1331A
K1331B
Table
4-1
LOOP
1
MAGLATCH
RELAYS
Selects
low
-
frequency
triangle
.
NC
Selects
high
-
frequency
triangle
.
Connects
75
load
to
Triangle
Buffer
.
Connects
loop
capacitor
C1411
into
loop
.
NC
(
a
)
Connects
loop
capacitor
C1211
into
loop
.
Inhibits
shrink
control
operation
.
Connects
loop
capacitor
C1421
into
loop
.
Selects
shrink
control
resistance
.
Conencts
loop
capacitor
C1422
into
loop
.
Selects
shrink
control
resistance
.
Strobed
+8
V
is
applied
to
P1510
,
pin
8A
,
which
pro
vides
the
current
path
for
the
relays
to
energize
.
(
The
emitters
of
the
Darlington
buffers
are
connected
to
the
+8
V
return
line
.
)
Once
a
driver
has
energized
,
a
relay
through
the
A
coil
,
for
example
,
the
relay
will
stay
latched
until
the
opposite
driver
pulls
the
relay
contact
to
the
B
side
.
Note
that
K1331
,
K1323
,
K1322
,
and
K1321
are
individually
controllable
,
and
that
K1231
and
K1131
are
cross
-
connect
ed
.
The
first
four
control
the
loop
timing
capacitors
,
as
noted
in
Table
4-1
.
The
remaining
two
are
cross
-
connected
to
en
sure
that
these
two
relays
are
mutually
exclusive
;
i.e.
,
the
two
triangle
signal
sources
are
never
connected
again
.
Theory
of
Operation
-
FG
5010
14
CLAMP
CIRCUITS
国
Introduction
Refer
to
Fig
.
4-9
,
which
is
a
block
diagram
of
the
Clamp
Circuits
.
The
TRIG
/
GATE
,
FREEGATE
,
BURST
,
END
OF
BURST
,
and
HFSQ
signals
are
applied
to
the
Trig
/
Gate
/
Burst
Logic
Circuit
.
This
is
the
mode
logic
that
deter
mines
the
Clamp
Enable
Switch
action
and
timing
.
The
FREEGATE
and
BURST
signals
set
the
modes
,
and
the
other
signals
provide
the
timing
for
the
events
from
the
cir
cuit
.
The
logic
circuit
also
ensures
that
the
main
loop
re
mains
running
during
Loop
2
operations
to
furnish
the
triangle
and
square
waves
to
the
Loop
2
circuits
.
The
Square
Selector
receives
the
HFSQ
,
HFSQ
,
Low
frequency
squarewave
,
and
data
signals
,
and
produces
the
output
selected
squarewave
signals
.
The
selection
is
con
trolled
by
the
HI
RANGE
input
line
.
Latch
U1141
receives
,
stores
and
applies
the
digital
data
that
controls
>
DAC
U1041
-
U1042A
.
This
circuit
produces
an
output
voltage
that
is
a
function
of
the
input
data
and
the
+10
V
reference
.
This
voltage
is
applied
to
two
networks
that
establish
a
difference
between
the
+10
V
reference
and
the
applied
voltage
.
The
difference
is
derived
by
two
separate
summing
networks
,
each
of
which
supplies
an
am
plifier
.
These
are
the
ø
Lock
Phase
Voltage
Generator
and
the
Clamp
Phase
Voltage
Generator
.
The
first
of
the
two
produces
a
voltage
that
is
applied
to
the
Loop
2
circuits
to
determine
the
relative
phase
between
the
FG
5010
output
signal
and
the
input
signal
during
phase
-
lock
operation
.
The
Clamp
Phase
Voltage
Generator
,
which
is
gated
by
the
Clamp
Enable
Switch
,
is
used
during
the
modes
where
the
loop
is
controlled
externally
;
i.e.
,
gated
,
triggered
,
and
burst
modes
.
The
stage
sets
the
point
at
which
the
loop
will
be
stopped
,
due
to
the
data
applied
from
U1141
.
The
Clamp
Enable
Switch
is
driven
by
the
logic
circuits
,
discussed
later
.
The
switch
steers
current
from
the
Clamp
Phase
Voltage
Generator
circuit
to
permit
free
-
running
the
main
loop
,
or
clamps
the
loop
by
shutting
off
the
current
path
.
The
circuit
also
enables
or
disables
the
Schmitt
Defeat
gate
,
which
does
not
operate
during
clamp
operations
.
$
DAC
The
DAC
produces
an
output
voltage
that
is
a
pro
grammed
fraction
of
the
+10
V
reference
.
The
circuit
con
sists
of
DAC
U1041
,
amplifier
U1042A
,
and
related
circuitry
.
Feedback
current
for
the
amplifier
is
through
the
internal
feedback
resistance
in
U1041
.
4-17
