Tektronix MDO3000 Series Service Manual

Replaceable Parts List
Fig. &
index
number
Tektronix
part numb er
Serial
no.
effective
Serial no.
discont’d Qty Name & description
7- FRONT PANEL ASSEMBLY
-15 105-1176-00 1
ACTUATOR, SWITCH, 10 KEY
878-0789-xx 1
CIRCUIT BOARD ASSEMBLY, FRONT PANEL, 2 CH
-16
878-0764-xx 1
CIRCUIT BOARD ASSEMBLY, FRONT PANEL, 4 CH
-17 131-8139-0
0
10
CONTACT, SPRING: FRONT PANEL ELEC
-18 351-1109-0
1
2
GUIDE, KEY; POLY, BAYBLEND FR-110
-19 213-1149-0
0
2
SCREW, TPG, TF; 2-28 X.5, PLASTITE, FLAT HEAD, PHILLIPS, STL, ZNPL
-20 259-0212-
00
1
CIRCUIT, FLEX; 10 KEY
-21 200-5301-
00
1
COVER; OPTION KEY DOOR, PC/ABS, FR110, SILVER GRAY
-22 200-5052
-00
1
COVER, FRONT PROTECTIVE
MDO3000 Series Mixed Domain O sc illoscopes Service Manual 25
