Replaceable Parts List
Table 4: Front p
anel assembly
Fig. &
index
number
Tektronix
part number
Serial
no.
effective
Serial no.
discont’d Qty Name & description
7- FRONT PANEL ASSEMBLY
050-3815-xx 1
PARTS REPLACEMENT KIT; 2 CH FRONT PANEL ASSEMBLY; INCLUDES THE
FOLLOWING PARTS:
FIGURE NUMBE
RS 9, 10, 14, 15 and 21
-1
050-3814-xx 1
PARTS REPLA
CEMENT KIT; 4 CH FRONT PANEL ASSEMBLY; INCLUDES THE
FOLLOWING PARTS:
FIGURE NUMBERS 9, 10, 14, 15 and 21
-2 366-0855-xx 2
ASSEMBLY, KNOB: 0.925 DIAMETER, SOFT TOUCH
-3 366-0857-xx 1
KNOB ASSEMBLY, SHUTTLE AND BUSHING
-4 358-0883-00 1
BUSHING (JOG SHUTTLE KNOB)
-5
366-0865-xx 1
KNOB ASSEMBLY, JOG
-6 366-0851-xx 6
ASSEMBLY, KNOB: 0.470 DIAMETER, SOFT TOUCH
-7
366-0853-xx 6
ASSEMBLY, KNOB: 0.685 DIAMETER, SOFT TOUCH
335-2664-00 1
LABEL. FRONT PANEL, OVERLAY, FRENCH
335-2665-00 1
LABEL. FRONT PANEL, OVERLAY, ITALIAN
335-2666-00 1
LABEL. FRONT PANEL, OVERLAY, GERMAN
335-2667-00 1
LABEL. FRONT PANEL, OVERLAY, SPANISH
335-2668-00 1
LABEL. FRONT PANEL, OVERLAY, JAPANESE
335-2669-00 1
LABEL. FRONT PANEL, OVERLAY, PORTUGUESE
335-2670-00 1
LABEL. FRONT PANEL, OVERLAY, SIMPLIFIED CHINESE
335-2671-00 1
LABEL. FRONT PANEL, OVERLAY, TRADITIONAL CHINESE
335-2672-00 1
LABEL. FRONT PANEL, OVERLAY, KOREAN
-8
335-2673-00 1
LABEL FRONT PANEL OVERLAY, RUSSIAN
-9 260-2857-00 1
SWITCH, KEYPAD, ELASTOMERIC, POWER
-10 407-5259-00 1
BRACKET, SUPPORT: POWER SWITCH
SCREW, PT, K35-1.57, PAN HEAD, STL, ZNPL, T-15 TORX DRIVE
------DISTRIBUTIONOFTHE211-1273-00 SCREWS ------
2 screws attach the Power switch and bracket to the front case assembly.
2 screws attach the Utility switch and bracket to the front case assembly.
10 screws attach the Front panel assembly to the front case assembly – with contact springs
(
#17).
-11 211-1273-00 19
5
screws across the bottom of the Front panel assembly attach it to the front case assembly
– without contact springs.
-12 260-2889-00 1
SWITCH, KEYPAD, ELASTOMERIC, UTILITY
-13 407-2567-00 1
BRACKET, SUPPORT, UTILITY SWITCH
-14 260-2971-00 1
SWITCH, KEYPAD, ELASTOMERIC, FRONT PANEL
24 MDO3000 Series Mixed Domain Oscilloscopes Service Manual
