Tektronix MDO4104-3 User Manual

Display Wavefor
morTraceData
3. Push Dots Only On Off from the side-bezel
menu. Dots on will display the waveform
record points
as dots on the screen. Dots off
connects the dots with vectors.
Waveform
Display
Dots Only
On |
Off
4. Push Persis
tence to Off to display the
display persistence.
Persis-
tence
On|Off
5. Push Persist Time, and turn multipurpose
knob a to ha
ve waveform data remain on
screen for a user-specified amount of time.
Persist
Time
(a) Auto
6. Push Set to
Auto to have the oscilloscope
automatically determine a persistence time
for you.
Set to Auto
7. Push Clear Persistence to reset the
persistence information.
Clear Per-
sistence
MDO4000 Series Oscilloscopes User Manual 97
