Analyze Wavefor
morTraceData
9. Push Edit Custom Mask from the
lower-bezel menu.
10. Turn multipur
pose knob a to adjust the
custom mask Vertical Margin,asshownin
the resulting side-bezel menu. A positive
value will sp
read the upper and lower mask
segments apart. A negative value will bring
the upper and lower segments together.
NOTE. For mo
re on editing capabilities, see the
“Create a custom mask from a text file” section
or the “Create a mask via a remote interface”
section.
Create a custom mask from a text file.
1. Push the front-panel Test button.
2. Push the lower-bezel menu Application
item. Turn multipurpose knob a to select
Limit/M
ask Test from the menu.
3. Push th
e lower-bezel Set Up Mask item.
MDO4000 Series Oscilloscopes User Manual 157
