Tektronix MSO4104

Performance Verification
Performance checks: Bandwidth
Bandwidth at
Channel Impedance Vertical scale V
in-pp
V
bw-pp
Limit
Test result
Gain =
V
bw-pp
/V
in-pp
4
50 Ω 2 mV/div
≥ 0.707
4
50 Ω 1 mV/div
≥ 0.707
4
1MΩ 5 mV/div
≥ 0.707
4
1MΩ 2 mV/div
≥ 0.707
4
1MΩ 1 mV/div
≥ 0.707
DC Gain Accuracy
Performance checks Vertical scale Low limit Test result High limit
All models:
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 mV
-3.0% 3.0%
5 mV/div -1.5% 1.5%
10 m V/div -1.5% 1.5%
20 m V/div -1.5% 1.5%
49.
8mV
-3.0% 3.0%
50 m V/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 1 DC Gain
Accuracy, 0 V offset,
0Vvert
ical position,
20 MHz BW, 50 Ω
1.0 V/div -1.5% 1.5%
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 m V /div -3.0% 3.0%
5 mV/div -1.5% 1.5%
10 m V/div -1.5% 1.5%
20 m V/div -1.5% 1.5%
49.8 mV
-3.0% 3.0%
50 m V/div -1.5% 1.5%
100 m V /div -1.5% 1.5%
200 m V /div -1.5% 1.5%
500 m V /div -1.5% 1.5%
Channel 1 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
20 MHz BW, 1 MΩ
1 V/div -1.5% 1.5%
MSO4000 and DPO4000 Series Specifications and Performance Verification 23
