Tektronix MSO4104

Performance Verification
DC Gain Accuracy
Performance checks Vertical scale Low limit Test result High lim it
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 mV
-3.0% 3.0%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
49.8 mV
-3.0% 3.0%
50 mV/div -1.5% 1.5%
100 m V/div -1.5% 1.5%
200 m V/div -1.5% 1.5%
500 m V/div -1.5% 1.5%
Channel 2 DC Gain
Accuracy, 0 V offset,
0Vverticalp
osition,
20 MHz BW, 50 Ω
1.0 V/div -1.5% 1.5%
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 m V /div -3.0% 3.0%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
4
9.8 mV
-3.0% 3.0%
50 mV/div -1.5% 1.5%
100 m V/div -1.5% 1.5%
200 m V/div -1.5% 1.5%
500 m V/div -1.5% 1.5%
Channel 2 DC Gain
Accuracy, 0 V offset,
0Vv
ertical position,
20 MHz BW, 1 MΩ
1 V/div -1.5% 1.5%
DPO4104, DPO4054, DPO4034, MSO4104, MSO 4054, MSO4034:
1 mV/div -1.5% 1.5%
2 mV/div -1.5% 1.5%
4.98 mV
-3.0% 3.0%
5 mV/div -1.5% 1.5%
10 mV/div -1.5% 1.5%
20 mV/div -1.5% 1.5%
49.8 mV
-3.0% 3.0%
50 mV/div -1.5% 1.5%
100 m V/div -1.5% 1.5%
200 m V/div -1.5% 1.5%
500 m V/div -1.5% 1.5%
Channel 3 DC Gain
Accuracy, 0 V offset,
0 V vertical position,
20 MHz BW, 50 Ω
1.0 V/div -1.5% 1.5%
24 MSO4000 and DPO4000 Series Specifications and Performance Verification
