Tektronix MSO4104

Performance Verification
Random No ise, Sample Acquisition Mode
Vertical sensitivity = 100 mV/div
Performance checks 1 MΩ 50 Ω
Bandwidth Test result (mV) High limit (m V) Test result (mV) High limit (mV)
DPO4054/MSO4054
Full 7.73 3.18
250 M Hz 5.30 3.36
Channel 1
20 M H z 3.82 3.31
Full 7.73 3.18
250 M Hz 5.30 3.36
Channel 2
20 M H z 3.82 3.31
Full 7.73 3.18
250 M Hz 5.30 3.36
Channel 3
20 M H z 3.82 3.31
Full 7.73 3.18
250 M Hz 5.30 3.36
Channel 4
20 M H z 3.82 3.31
DPO4034/MSO4034
Full 6.54 3.38
250 M Hz 4.89 3.28
Channel 1
20 M H z 3.42 3.12
Full 6.54 3.38
250 M Hz 4.89 3.28
Channel 2
20 M H z 3.42 3.12
Ful
l
6.5
4
3.3
8
250 M Hz 4.89 3.28
Channel 3
20 M H z 3.42 3.12
Fu
ll
6.
54
3.
38
250 M Hz 4.89 3.28
Channel 4
20 M H z 3.42 3.12
DPO4032/MSO4032
Full 7.34 3.18
250 M Hz 4.99 3.97
Channel 1
20 M H z 3.12 3.61
Full 7.34 3.18
250 M Hz 4.99 3.97
Channel 2
20 M H z 3.12 3.61
MSO4000 and DPO4000 Series Specifications and Performance Verification 29
