Tektronix MSO4104

Performance Verification
DC Offset Accuracy
Performance
checks Vertical scal
e
Vertical offs
et
1
Low limit Test result
High limit
1mV/div
900 mV 895.2 mV 904.8 mV
1mV/div
-900 mV -904.8 m V -895.2 m V
2mV/div
500 mV 497.1 mV 502.9 mV
2mV/div
-500 mV -502.9 m V -497.5 m V
10 mV/div
500 mV 495.5 mV 504.5 mV
10 mV/div
-500 mV -504.5 m V -495.1 m V
100 mV/div
5.0 V 4.955 V 5.045 V
100 mV/div
-5.0 V -5.045 V -4.955 V
1.01 V/div
99.5 V 98.80 V 100.2 V
Channel 4 DC Offset
Accuracy,
20 MHz BW, 1 MΩ
1.01 V/div
-99.5 V -100.2 V -98.80 V
1
Use this value for both the calibrator output and the oscilloscope offset setting.
Performance checks Low limit Test result High limit
Sample Rate and Delay Time Accuracy
-1 divisions +1 divisions
Auxiliary (Trigger) Output
High 1 MΩ
≥ 2.5 V
–
Trigger Output
Low 1 M Ω
–
≤ 0.7 V
High 50 Ω
≥ 1.0 V
–
Trigger Output
Low 50 Ω
–
≤ 0.25 V
Random Noise, Sample Acquisition Mode
Vertical sensitivity = 100 mV/div
Performance checks 1 M Ω 50 Ω
Bandwidth Test result (mV) High lim it (mV) Test result (mV) High limit (mV)
DPO4104/MSO4104
Full 7.43 6.07
250 M H z 5.10 3 .75
Channel 1
20 MHz 3.32 3.31
Full 7.43 6.07
250 M H z 5.10 3 .75
Channel 2
20 MHz 3.32 3.31
Full 7.43 6.07
250 M H z 5.10 3 .75
Channel 3
20 MHz 3.32 3.31
Full 7.43 6.07
250 M H z 5.10 3 .75
Channel 4
20 MHz 3.32 3.31
28 MSO4000 and DPO4000 Series Specifications and Performance Verification
