Installing your instrument
Check shipped accessories
Make sure that you received everything you ordered. If anything is missing, contact Tektronix Customer Support. In North
America, call 1-800-833-9200. Worldwide, visit www.tek.com to find contacts in your area.
Check the packing list that came with your instrument to verify that you have received all standard accessories and ordered
items. If you purchased factory installed options such as a Serial Bus and Triggering option, or the Power measurements option,
tap Help > About to confirm that the option(s) are listed in the Installed Options table.
MSO44, MSO46 standard accessories
Item Quantity Tektronix part number
4 Series MSO (MSO44, MSO46) Installation and Safety Manual 1 071-3644-xx
TPP0250 Passive Voltage Probe (250 MHz bandwidth). Shipped with
200 MHz models
4
1
TPP0250
TPP0500B Passive Voltage Probe (500 MHz bandwidth). Shipped with
350 MHz, 500 MHz, 1 GHz and 1.5 GHz models
4
1
TPP0500B
Accessory pouch 1 016-2143-xx
Power cord 1 Depends on region
Calibration certificate 1 N/A
Report of factory installed licenses 1 N/A
Safely rotate the handle
Use the correct process to eliminate the chance of pinching your thumb or rear-panel-connected cables while rotating the handle.
CAUTION. Hold the top of the handle to rotate the handle on the instrument. Do not hold the handle from the sides and rotate, as
this can pinch the base of your thumb between the handle and the case.
If you have routed any cables between the handle and the case, be careful when rotating the handle so that you do not pinch the
cables.
1
Four probes are shipped with 4- and 6-channel models.
MSO44, MSO46 Installation and Safety Manual 1
