Task Touchscreen UI action Mouse action
Move a note
3
. Touch and hold on a note and quickly
4
start to drag, then move to new position.
Click and hold the right mouse button on
the note and quickly start to drag, then
move to the new position.
Change horizontal or vertical settings
directly on a waveform.
Vertical changes only apply to the
selected channel or waveform; horizontal
changes apply to all channels and
waveforms.
Tap a badge and use the Scale buttons.
Touch and hold two fingertips on the
waveform view, move them together or
apart vertically or horizontally, lift from
screen; repeat.
Left-click a channel, waveform, or
Horizontal badge and click on the Scale
buttons.
Increase or decrease the zoom area
(while in Zoom mode)
Touch and hold two fingertips on the
waveform view, move them together or
apart vertically or horizontally, lift from
screen; repeat.
Click the + or - buttons on the Zoom Title
bar.
Click the Draw-a-Box button, draw a box
around the waveform area of interest.
Quickly scroll or pan a waveform or list. Touch and drag in the waveform or list. Click and drag in the waveform or list.
Close or open the Results Bar to
increase the Waveform View area.
Tap on the Results Bar Handle (three
vertical dots in border) or anywhere in the
border between the Waveform View and
the Results Bar.
Click the Results Bar Handle (three
vertical dots in border) or anywhere in the
border between the Waveform View and
the Results Bar.
Click and drag the Results Bar divider.
Change the position of badges in the
Settings Bar or Results Bar.
See the Help topic Rearranging waveform
and measurement badges for more
information on moving badges.
Touch and drag the badge to a new
position in the same bar.
Click and drag the badge to a new
position in the same bar.
3
Notes are screen objects and are not associated with any particular waveform channel or slice.
4
Start to move the note as soon as selected (highlighted), otherwise the UI opens the right-click menu.
Getting acquainted with your instrument
MSO44, MSO46 Installation and Safety Manual 29
