Specifications
P5205 Instruction Manual
17
Table 3: Certifications and Compliances (Cont.)
Installation Category
Descriptions
Terminals on this product may have different installation category
designations. The installation categories are:
CAT III Distribution-level mains (usually permanently
connected). Equipment at this level is typically
in a fixed industrial location
CAT II Local-level mains (w all sockets). Equipment at
this level includes appliances, portable tools,
and similar products. Equipment is usually
cord-connected
CAT I Secondary (signal level) or battery operated
circuits of electronic equipment
Pollution Degree 2 Do not operate in environments where conductive pollutants may
be present.
Typical Characteristics
Typical characteristics in Tables 4 and 5 describe typical but not
guaranteed performance.
Table 4: Typical Electrical Characteristics
Rise Time 3.5 ns
Bandwidth Limit 5MHz
AC Common-Mode Rejection Ratio
(20
-30_C, <70% RH)
See Figure 5 on page 18
60 Hz: > 10,000:1
100 kHz: > 300:1
100 MHz: > 300:1
AC Noise
(referenced to input)
50X: < 50 mV
RMS
500X: < 300 mV
RMS
Input Impedance
8MΩ, 3.5 pF between inputs
4MΩ, 7 pF between each input and ground
SeeFigure6
Propagation Delay 17 nS
