Performance Verification
The following procedure verifies the warranted electrical characteris-
tics of the High Voltage Differential Probe. Table 7 itemizes the
equipment required, provides an example or part number of the
equipment, and explains the purpose of the equipment.
Table 7: List of equipment required
Description
Minimum
requirements
Example or part
number Purpose
Test oscilloscope Bandwidth: ≥ 400 MHz
TEKPROBE interface
vertical accuracy:
≤ 1.5%
TDS460A
or TDS744A
Display probe output
Calibration
generator
Amplitude accuracy:
≤ 0.75%
Rise time: ≤ 3ns
Wavetek 9100
with oscilloscope
option
Check probe
attenuation, rise time
Calibrator Up to 500 VDC output Fluke 5100B Check common mode
rejection ratio
Plunger clamps
(2 required)
Use clamps included in
accessory kit
Accessory kit
020-2106-00
Connection to binding
post
BNC adapter BNC-male-to-dual
binding post
103-0035-00 Interconnection
between probe and
generator
Modified BNC
adapter
BNC-male-to-dual
binding post
103-0035-00 Interconnection be-
tween probe and gen-
erator. (See Figures 11
and 13).
BNC adapter BNC-female-to-dual
banana
103-0090-00 Interconnection be-
tween probe and gen-
erator
