Table of Contents
P5205 Instruction Manual
iii
List of Figures
Figure 1: P5205 High-Voltage Differential Probe 2...........
Figure 2: Safety limits (voltage between either i nput and
earth ground) 11....................................
Figure 3: Twisting the input leads 13.......................
Figure 4: HF transient response with and without extension
leads 14..........................................
Figure 5: Typical common-mode rejection ratio
(50X attenuation) 18.................................
Figure 6: Input impedance vs. frequency 19.................
Figure 7: Replacing TEKPROBE interface pins 22............
Figure 8: Replacing the TEKPROBE collar 23...............
Figure 9: Removing the compensation box covers 24..........
Figure 10: Replacing the compensation box cover 25..........
Figure 11: BNC-male-to-dual binding post adapter 28.........
Figure 12: Removing plastic covers from binding posts 29.....
Figure 13: Slide probe leads onto the binding posts 30.........
Figure 14: P5205 Probe and replaceable accessories 35........
Figure 15: Replaceable parts -- compensation box 38..........
Figure 16: P5205 optional accessories 39...................
