P6015A Instruction Manual
2–1
Performance Verification
The performance verification procedure verifies that the P6015A
performs as described in the Specifications section of Chapter 1. This
procedure can also be used as an acceptance check. The procedure is
given in the next section, Adjustments.
The performance verification consists of the long-form compensa-
tion procedure with an additional step to check bandwidth and rise
time:
1. Check DC attenuation and adjust if necessary
2. Check low-frequency compensation and adjust if necessary
3. Check transient response and adjust if necessary
4. Check bandwidth and calculate rise time
