Replaceable Parts
2–21P6015A Instruction Manual
Fig. &
Index No.
Tektronix
Part No.
Serial No. Effective
Dscont
Qty
12345
Name & Description
Mfr.
Code
Mfr. Part No.
2–5–
STANDARD (10 FT CABLE–NO READOUT)
–1 344–0461–00 1 CLIP,ELEC:CROCODILE,82MM L,4MM TK2483 XK–081
–2 196–3363–00 1 LEAD ELECTRICAL:GROUND,STRD,18 AWG,10.0L 80009 196336300
–3 204–1106–00
204–1106–01
B010100
B020000
B019999 1
1
BODY,PROBE:OUTER,FINISHED
BODY,PROBE:OUTER,FINISHED
80009
80009
204110600
204110601
–4 206–0116–00 1 TIP,PROBE: 80009 206011600
–5119–4636–00
––––––––
––––––––
B020000 1
1
1
PROBE,HV:75MHZ,10 FT;FOR EXCHANGE ONLY
.BODY ASSY,PROBE:
.COMP BOX ASSY:
80009 119463600
–6 367–0438–00 1 HANDLE,PROBE:6.0 L,NYLON,GRAY 80009 367043800
–7 174–2579–00 1 CABLE ASSY,RF:50 OHM COAX,10FT L 80009 174257900
–8 131–0602–00
016–1147–00
070–8223–04
1
1
1
CONN,RF PLUG:BNC,;50 OHM,MALE,STR,
FEEDTHRU/FRONT PNL,1.555 L,0.285 L 0.375–32 THD,0.5L
22 AWG TAB,0.384 DIA MTG
STANDARD ACCESSORIES
CASE,CRYG,PROBE:
MANUAL,TECH:INSTR,P6015A
24931
80009
80009
28PR104–1
016114700
070822304
–9 344–0005–00
206–0463–00
B010100
B020000
B019999 1
1
CLIP,ELECTRICAL:ALLIGATOR,2.5 L,W/PLUG & COVER
TIP,HOOK:PROBE
80009
80009
344000500
206046300
–10 134–0016–00 B020000 1 PLUG,TIP:BANANA,10–32 INT THD END 74970 23.29–7
