Tektronix RSA5BUP Technical Reference

Specifications
Table 49: P25 analysis (Option 26) (cont.)
Characteristic Description
Phase 2 (HDQPSK)
–75 dBc
62.5 kHz offset from the center and
bandwidth of 6 kHz, typical
–76 dBc
Table 50: Bluetooth® analysis (Option 27)
Characteristic Description
Supported standards Bluetooth® 4.1 Basic Rate (BR) (power classes 1 to 3)
Bluetooth® 4.1 Low Energy (LE)
Packet types: DH1, DH3, DH5 (BR), Reference (LE)
Output power
Supported measurements
Average power, peak power
Level uncertainty
Refer to (See Table 9 on page 8.)
Measurement range
Signal level >-70 dBm
Basic Rate modulation c haracteristics (center frequency = 2400 MHz to 2500 MHz)
Supported measurements F1avg, F2avg, F2avg/ F1avg, F2max% 115 kHz
Deviation range ±280 kHz
Deviation uncertainty
<2 kHz + RSA frequency uncertainty
Measurement resolution 10 Hz
Measurement range
Nominal channel frequency ±100 kHz
RF signal power range >-70 dBm
Low Energy modulation characteristics (center frequency = 2400 MHz to 2500 MHz)
Supported measurements F1avg, F2avg, F2avg/ F1avg, F2max% 185 kHz
Deviation range ±280 kHz
Deviation uncertainty
<3 kHz + RSA frequency uncertainty
Measurement resolution 10 Hz
Measurement range
Nominal channel frequency ±100 kHz
RF signal power range >-70 dBm
Initial carrier frequency tolerance (ICFT)
Measurement uncertainty
<1 kHz + RSA frequency uncertainty
Measurement resolution 10 Hz
Measurement range
Nominal channel frequency ±100 kHz
RF signal power range >-70 dBm
Carrier frequency drift
Supported measurements Max freq. offset, drift f
1
-f
0
, max drift f
n
-f
0
, max drift f
n
-f
n-5
(BR and LE 50 s)
Measurement uncertainty
<1 kHz + RSA frequency uncertainty
Measurement resolution 10 Hz
Measurement range
Nominal channel frequency ±100 kHz
52 RSA5100B Series Technical Reference
