Specifications
Table 50: Bluetooth® analysis (Option 27) (cont.)
Characteristic Description
RF signal power range >-70 dBm
In-band emissions (ACPR) level uncertainty Refer to (See Table 9 on page 8.)
Table 51: A
CLR measurement
Characteristic Description
ACLR (3GPP Down Link, 1 DPCH)
(2130 MHz), typical
–69 dBc (Adjacent Channel)
–75 dBc w/Noise Correction (Adjacent Channel)
–70 dBc (
First Alternate Channel)
–77 dBc w/Noise Correction (First Alternate Channel)
Table 52: Digital phosphor spectrum processing (DPX)
Characteristic Description
Spectrum Processing Rate, nominal Standard: 390,625 per second (Span Independent)
Option 300 with Option 09: 3,125,000 per second (Span/RBW ratio 333)
390,625 per second (Span/RBW ratio > 333)
DPX Bitmap Image Resolution, nominal 201 pixels vertical x 801 pixels horizontal
DPX Bitmap Color Dynamic Range, nominal
2
33
levels
Min Signal Duration for 100% Probability of
intercept, typical
Same as Frequency Mask Trigger Minimum Signal Duration
Span Range, nominal 100 Hz to 25 MHz (Std)
100 Hz to 40 MHz (Opt. B40)
100 Hz to 85 MHz (Opt. B85)
100 Hz to 125 MHz (Opt. B125)
100 Hz to 165 MHz (Opt. B16x)
Swept Span Range, nominal Up to instrument frequency range
Dwell Time per Step (Swept Spans), nominal
5msto100s
RSA5100B Series Technical Reference 53
