Table 52: Digital phosphor spectrum processing (DPX) (cont.)
Characteristic Description
Standard, Span = 25 MHz Option B 40, Span = 40 MHz
FMT RBW Minimum event
duration (μs)
FMT RBW Minimum event
duration (μs)
5MHz 4.0 5MHz 3.9
1MHz 5.8 1MHz 5.8
100 kHz 27.5 300 kHz 11.4
10 kHz 267.8 100 kHz 30.8
10 kHz 294.5
Option B85/B125/B16x,
Span = 85/125/160 MHz
1
FMT RBW Minimum event
duration (μs)
10 MHz 3.7
1MHz 5.8
Frequency Mask Trigger
Real-time Event Min Signal Duration for 100%
Probability of Trigger, typical
100 kHz 37.6
RBW Settings, nominal RBW (Min) RBW (Max)
165 MHz (Option B16x)
25 kHz 20 MHz
125 MHz (Option B125)
19 kHz 10 MHz
85 MHz (Option B85)
12.9 kHz 10 MHz
60 MHz (Option B85)
9.1 kHz 9.12 MHz
40 MHz (Option B40/B85)
6.1 kHz 6.08 MHz
25 MHz 3.79 kHz 3.8 MHz
20 MHz 3.03 kHz 3.04 MHz
10 MHz 1.52 kHz 1.52 MHz
5 MHz 758 Hz 760 kHz
2 MHz 303 Hz 304 kHz
1 MHz 152 Hz 152 kHz
500 kHz 75.8 Hz 76.0 kHz
200 kHz 30.3 Hz 30.4 kHz
100 kHz 15.2 Hz 15.2 kHz
50 kHz 7.58 Hz 7.6 kHz
20 kHz 3.03 Hz 3.04 kHz
10 kHz 1.52 Hz 1.52 kHz
54 RSA5100B Series Technical Reference
