Tektronix RSA5BUP Technical Reference

Specifications
Table 55: Frequency Settling Time measurement (Option 12)
1
(cont.)
Measurement frequency, averages Settled Frequency Uncertainty at stated measurement bandwidth
165 MHz
BW
125 MHz
BW
85 MHz
BW
10 MHz
BW
1MHz
BW
100 kHz
BW
1000 Averages 100 Hz 100 Hz 100 Hz 5 Hz 0.5 Hz 0.1 Hz
20 GHz
Single measurement
2 kHz 2 kHz 2 k Hz 100 Hz 10 Hz 5 Hz
100 Averages 200 Hz 200 Hz 200 Hz 10 Hz 1 H z 0.5 Hz
1000 Averages 100 Hz 100 Hz 100 Hz 5 Hz 0.5 Hz 0.2 Hz
Reference information: Measured input signal > –20 dBm, Attenuator: Auto
1
Settled Frequency Uncertainty, 95% co nfidence.
Table 56: AM/FM/PM and Direct audio measurements (Option 10)
1
Characteristic Description Reference information
Analog demodulation
Carrier frequency range (for modulation and
audio measurements)
9 kHz or ½ × (Audio Analysis Bandwidth)
to maximum input frequency
Maximum audio frequency span
10 MHz
Global Conditions for Audio Measurements Input Frequency: <2 GHz
RBW: Auto
Averaging: Off
Filters: Off
FM Performance: Modulation Index >0.1
Audio filters
Low Pass (kHz)
0.3, 3, 15, 30, 80, 300, and user-entered
up to 0.9 × audio bandwidth
High Pass (Hz)
20, 50, 300, 400, and user-entered up to
0.9 × audio bandwidth
Standard CCITT, C-Message
De-emphasis (µs)
25, 50, 75, 750, and user-entered
File
User-supplied .txt or .csv file of
amplitude/frequency pairs. Up to 1000
amplitude/frequency pairs supported.
RSA5100B Series Technical Reference 57
