Tektronix TBS1000B Series

Power source
Power source voltage 100 to 240 V ±10%
Power source frequency
100 V to 240 V 50 Hz to 60 Hz
115 V 400 Hz ±10%
Power consumption 30 W maximum
Physical characteristics
Dimensions
mm in.
Height 158.0 6.22
Width 326.3 12.85
Depth 124.2 4.89
Shipping dimensions
mm in.
Height 266.7 10.5
Width 476.2 18.75
Depth 228.6 9.0
Weight
kg lb.
Instrument only 2.0 4.3
...with accessories 2.2 4.9
RM2000B rackmount
mm in
Width 482.6 19.0
Height 177.8 7.0
Depth 108.0 4.25
Specifications
TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual 121
