Power distribution system
Power consumption 30 W (typ)
Source voltage Full range: 100 to 240 VACRMS ± 10%, Installation Category II (covers range of 90 to 264 V
AC
)
Power source 100 to 240 VAC RMS ±10%
Power source frequency 45 Hz to 65 Hz (100 to 240 V).
360 Hz to 440 Hz (100 to 132 V).
Fuse rating 3.15 Amps, T rating, 250 V; IEC and UL approved.
Mechanical characteristics
Weight
kg Lb
Instrument only 1.979 4.36
Instrument with accessories 3.112 6.86
Cooling clearance 50 mm (2 in) required on left side, right side and rear of instrument.
RM2000B rackmount
mm In
Height 177.8 7.0
Width 482.6 19.0
Depth 108.0 4.25
Shipping dimensions
mm In
Height 266.7 10.5
Width 476.2 18.75
Depth 228.6 9.0
Dimensions
mm In
Height- Handle folded down 154.95 6.1
Height-Handle up 213.36 8.4
Width 325.12 12.8
Depth 106.68 4.2
Cooling method Convection cooled
Specifications
TBS1000C Series Specification and Performance Verification 11
