Tektronix TBS1000C Series Technical Reference

Performance verification
This chapter contains performance verification procedures for the specifications marked with the check mark. The following
equipment, or a suitable equivalent, is required to complete these procedures.
Required equipment
Table 1: Performance verification
Description Minimum requirements Examples
DC voltage source 17.5 mV to 7 V, ±0.5% accuracy Wavetek 9100 Universal Calibration System
with Oscilloscope Calibration Module (Option
250)
Fluke 5500A Multi-product Calibrator with
Oscilloscope Calibration Option (Option
5500A-SC)
Leveled sine wave Generator 50 kHz and 200 MHz, ±3% amplitude
accuracy
Time mark generator 10 ms period, ±10 ppm accuracy
50Ω BNC cable BNC male to BNC male, ≈ 1 m (36 in) long Tektronix part number 012-0482-XX
50Ω BNC cable BNC male to BNC male, ≈ 25 cm (10 in) long Tektronix part number 012-0208-XX
50 Ω feed through termination BNC male and female connectors Tektronix part number 011-0049-XX
Dual banana to BNC adapter Banana plugs to BNC female Tektronix part number 103-0090-XX
BNC T adapter BNC male to dual BNC female connectors Tektronix part number 103-0030-XX
Splitter, power Frequency range: DC to 4 GHz. Tracking:
>2.0%
Tektronix part number 015-0565-XX
Adapter (four required) Male N-to-female BNC Tektronix part number 103-045-XX
Adapter Female N-to-male BNC Tektronix part number 103-0058-XX
Leads, 3 black Stacking banana plug patch cord, ≈ 45 cm
(18 in) long
Pomona #B-18-0
Leads, 2 red Stacking banana plug patch cord, ≈ 45 cm
(18 in) long
Pomona #B-18-2
TBS1000C Series Specification and Performance Verification 13
