Options Settings or submenus Comments
Select File Lists the contents of the current USB flash drive
folder and displays the next folder option
Change Folder See File management conventions on page 63
and File utilities for the USB flash drive on
page 110.
To Specifies the reference memory location to
recall the waveform to
Recall filename (such as
TEK0000.CSV)
Loads the waveform from the specified file to the
location in reference memory and displays the
waveform
Key points
Saving and Recalling Setups. The complete setup is stored in nonvolatile
memory. When you recall the setup, the oscilloscope will be in the mode from
which the setup was saved.
The oscilloscope saves the current setup if you wait three seconds after the last
change before you power off the oscilloscope. The oscilloscope then recalls this
setup the next time you apply power.
Recalling the Default Setup. You can push the Default Setup button to
initialize the oscilloscope to a known setup. To view option and control settings
that the oscilloscope recalls when you push this button, refer to Appendix D:
Default Setup.
Saving and Recalling Waveforms. The oscilloscope must display any waveform
that you want to save. Two-channel oscilloscopes can store two reference
waveforms in internal nonvolatile memory. Four-channel oscilloscopes can store
four, but only display two at a time.
The oscilloscope can display both reference waveforms and channel waveform
acquisitions. Reference waveforms are not adjustable, but the oscilloscope
displays the horizontal and vertical scales at the bottom of the screen.
Reference
100 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
