Menu or system Option, button, or knob Default setting
Vertical system, all channels Coupling DC
BW Limit Off
Vertical scale (volts/division) Coarse
Probe Voltage
Voltage Probe Attenuation 10X
Current Probe Scale 10 A/V
Invert Off
Position 0.00 divs (0.00 V)
Scale (volts/division) 1.00 V
The Default Setup button does not reset the following settings:
■
Language option
■
Saved setups
■
Saved reference waveforms
■
Calibration data
■
GPIB setup
■
Probe setup (type and attenuation factor)
■
Date and time
■
Current folder on the USB flash drive
Default setup
140 TBS1000B and TBS1000B-EDU Series Oscilloscopes User Manual
