Preface
This service manual provides information to verify performance of, calibrate,
troubleshoot, disassemble, and replace parts on the TBS1000 Series Digital
Storage Osci
lloscopes.
Unless noted otherwise, the term "oscilloscope" refers to all models in the
TBS1000 ser
ies.
Manual Conventions
This manu
al uses certain conventions that you should become familiar with
before attempting service.
Modules
Throughout this manual, any replaceable component, assembly, o r part is referred
to by the
term module.
A module is composed of electrical and mechanical assemblies, circuit cards,
interc
onnecting cables, and user-accessible controls.
Replaceable Parts
This manual refers to any field-replaceable assembly or mechanical part
specifically by its name or generically as a repla ceable part. In genera l, a
repl
aceable part is any circuit board or assembly, such as the hard disk drive, or a
mechanical part, such as the I/O port c onnectors, that is listed in the replaceable
parts list.
Safety
Sym
bolsandtermsrelatedtosafetyappearintheServiceSafetySummaryfound
at the beginning of this manual.
Related Documentation
To read about Use these documents
I
nstallation and
Operation
T
he oscilloscope user manual, available on the Tektronix Web
site.Go to www.tektronix.com/manuals and search for the user
manual for your product (available in 11 languages).
Programmer
Commands
The oscilloscope programmer manual, available on the Tektronix
Web site. Go to www.tektronix.com/manuals and search for the
programmer manual for your product.
TBS1000 Series Oscilloscope Service Manual ix
