Appendix A: Options and Accessories
Appendices
AĆ6
H
P6204 Active, high speed digital voltage probe. FET. DC to 1 GHz. DC
offset. 50
W
input. Use with 1103 TekProbe Power Supply for offset
control.
H
P6563AS Passive, SMD probe, 20X, 500 MHz
H
P6046 Active, differential probe, 1X/10X, DC to 100 MHz, 50
W
input.
H
A6501 Buffer Amplifier (active fixtured), 1 GHz, 1 M
W
10X.
H
P6501 Option 02: Microprobe with TekProbe power cable (active fixtured),
750 MHz, 1 M
W
10X.
H
AM 503S — DC/AC Current probe system, AC/DC. Uses A6302 Current
Probe.
H
AM 503S Option 03: DC/AC Current probe system, AC/DC. Uses A6303
Current Probe.
H
P6021 AC Current probe. 120 Hz to 60 MHz.
H
P6022 AC Current probe. 935 kHz to 120 MHz.
H
CT-1 Current probe — designed for permanent or semi-permanent in-
circuit installation. 25 kHz to 1 GHz, 50
W
input.
H
CT-2 Current probe — designed for permanent or semi-permanent in-
circuit installation. 1.2 kHz to 200 MHz, 50
W
input.
H
CT-4 Current Transformer — for use with the AM 503S (A6302) and
P6021. Peak pulse 1 kA. 0.5 Hz to 20 MHz with AM 503S (A6302).
H
P6701A Opto-Electronic Converter, 500 to 950 nm, DC to 850 MHz,
1 V/mW.
H
P6703A Opto-Electronic Converter, 1100 to 1700 nm, DC to 1 GHz,
1 V/mW.
H
P6711 Opto-Electronic Converter, 500 to 950 nm, DC to 250 MHz,
5 V/mW.
H
P6713 Opto-Electronic Converter, 1100 to 1700 nm, DC to 300 MHz,
5 V/mW.
H
TVC 501 Time-to-voltage converter. Time delay, pulse width and period
measurements.
Probe Accessories
The following optional accessories are recommended for use with the stan-
dard probe listed under
Standard Accessories.
