Table A-7: Factory Initialization Defaults (Cont.)
Control Changed by Factory Init to
Delay trigger average # 16
Delay trigger envelope # 10
Delay time 16 ns
Delay events,
triggerable after main
2
Delayed, delay by ... Delay by Time
Delayed, time base mode Delayed Runs After Main
Display clock No Change
Display color – collision contrast
(TDS 644A & TDS 524A)
Off
Display color – map math colors
(TDS 644A & TDS 524A)
Color ‘Math’
Display color – map reference colors
(TDS 644A & TDS 524A)
Color ‘Ref’
Display color – palette
(TDS 644A & TDS 524A)
Normal
Display color – palette colors
(TDS 644A & TDS 524A)
The colors of each palette are re-
set to factory hue, saturation, and
lightness (HLS) values
Display color – persistence palette
(TDS 644A & TDS 524A)
Temperature
Display format YT
Display graticule type Full
Display intensity – contrast
(TDS 620A & TDS 640A)
175%
Display intensity – text TDS 620A & TDS 640A: 60%
TDS 644A & TDS 524A: 100%
Display intensity – waveform TDS 620A & TDS 640A: 80%
TDS 644A & TDS 524A: 100%
Display intensity – overall
(TDS 620A & TDS 640A)
85%
Display interpolation filter Sin(x)/x
Display style Vectors
Display trigger bar style Short
Display trigger “T” On
