Acquisition
Operating Basics
2Ć24
H
Ground (GND) coupling disconnects the input signal from the acquisition.
H
Input impedance lets you select either 1 M
W
or 50
W
impedance.
NOTE
If you select 50
W
impedance with AC coupling, the digitizing oscillo-
scope will not accurately display frequencies under 200 kHz.
See
Scaling and Positioning Waveforms
, on page 2-25.
See
Acquisition Modes
, on page 3-3.
