Nominal Traits
2–10
TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications
Table 2–4: Nominal traits — Time base system
Name Description
Range, Sample-Rate
1,3
TDS 684B: 5 Samples/sec to 5 GSamples/sec on four channels simultaneously
TDS 680B: 5 Samples/sec to 5 GSamples/sec on two channels simultaneously
TDS 644B: 5 Samples/sec to 2.5 GSamples/sec on four channels simultaneously
TDS 620B: 5 Samples/sec to 2.5 GSamples/sec on two channels simultaneously
TDS 520C and 724C: 5 Samples/sec to 1 GSamples/sec when acquiring 1 channel,
to 500 MSamples/sec when acquiring 2 channels
TDS 540C: 5 Samples/sec to 2 GSamples/sec when acquiring 1 channel,
to 1 GSample/sec when acquiring 2 channels,
or to 500 MSamples/sec when acquiring 3 or 4 channels
TDS 754C: 5 Samples/sec to 2 GSamples/sec when acquiring 1 or 2 channels,
to 1 GSamples/sec when acquiring 3 or 4 channels
TDS 784C: 5 Samples/sec to 4 GSamples/sec when acquiring 1 channel,
to 2 GSample/sec when acquiring 2 channels,
or to 1GSamples/sec when acquiring 3 or 4 channels
Range, Interpolated Waveform Rate
2,3
TDS 600B: 10 GSamples/sec to 250 GSamples/sec
TDS 520C, 540C, 724C, and 754C: 1 GSamples/sec to 100 GSamples/sec
TDS 784C: 2 GSamples/sec to 250 GSamples/sec
Range, Seconds/Division TDS 600B: 0.2 ns/div to 10 s/div
TDS 500C, 724C, and 754C: 0.5 ns/div to 10 s/div
TDS 784C: 0.2 ns/div to 10 s/div
