Performance Tests

TDS 500C, TDS 600B & TDS 700C Performance Verification and Specifications

1–27

Signal Acquisition System Checks

These procedures check those characteristics that relate to the signal-acquisition

system and are listed as checked under Warranted Characteristics in Specifica-

tions.

Equipment

required

None

Prerequisites The oscilloscope must meet the prerequisites listed on page 1–15.

See Input Channels vs. Model on page 1–2.

1. Preset the instrument controls:

a. Initialize the oscilloscope:

H Press save/recall SETUP.

H Press the main-menu button Recall Factory Setup.

H Press the side-menu button OK Confirm Factory Init.

H Press CLEAR MENU to remove the menus from the screen.

b. Modify the default settings:

H Press SHIFT; then press ACQUIRE MENU.

H On the TDS 600B, press the main-menu button Mode; then press the

side-menu button Average 16.

H On the TDS 500C and 700C, press the main-menu button Mode;

then press the side-menu button Hi Res.

H Press CURSOR.

H Press the main-menu button Function; then press the side-menu

button H Bars.

H Press CLEAR MENU.

H Be sure to disconnect any input signals from all four channels.

2. Confirm input channels are within limits for offset accuracy at zero offset:

Do the following substeps — test CH 1 first, skipping substep a since CH 1

is already set up to be checked from step 1.

a. Select an unchecked channel: Press WAVEFORM OFF to remove the

channel just confirmed from the display. Then, press the front-panel

button that corresponds to the channel you are to confirm.

Check Offset Accuracy

(Zero Setting)
