Adjustment Procedures

TDS 500B, 600B and TDS 700A Service Manual

5–23

H Press the main-menu button EXECUTE; then press the side-menu

button Ok Confirm Run Test.

b. Make the contrast adjustment:

H Locate R572. It is one of two adjustments on the left side of the

instrument located just ahead of the fan. It is the adjustment nearest

the front of the oscilloscope.

H Monitor the luminance at center screen using a J16 photometer and a

luminance probe.

H Adjust R572 (CONTRAST) for a reading of 50 foot lamberts if the

gray display shield is installed; adjust for 110 foot lamberts if the

shield is missing.

4. Restore the oscilloscope to normal operation:

a. Restore the dip switch to the settings that follow:

Switch No. 1 2 3 4 5 6 7 8

Open

Closed X X X X X X X X

b. Power off the oscilloscope.

c. See Removal and Installation Procedures in Section 6 to reinstall the

cabinet and other modules removed in step 1.
