Getting Started
Installing the Battery
To install t he optional battery pack, follow these steps:
1. Open the battery compartment door on the rear panel.
2. Remove the accessory tray.
Battery door (opened)
3. Slide the batter y into the compartment and press it in from b oth
sides until you hear the latches click.
4. Press on both sides of the battery com partment door to snap it
closed.
To remove th e bat ter y, follow these steps:
1. Open the battery compartment door.
2. Raise the handles on each side of the battery and use them to pull
the battery o ut o f t he oscilloscope.
12 TDS3000C Series Oscilloscope User Manual
