Operating Information
1-14
TDS3000C Series S ervice Manual
20 2321 22
20. Hard copy . Initiates a hard copy using the port selected in the Utility menu.
21. Power. Turns power to on or standby.
22. Wrist-strap ground. Use to connect a wrist strap when working with
ESD-sensitive circuits. This connector is not a safety ground.
23. Menu Off. Clears menu from the display.
