Specifications
TDS3000 Series Service Manual
1–5
Table 1–1: Specifications (cont.)
Horizontal
Acquisition (horizon-
tal) resolution
Normal Fast trigger
Record length 10,000 points 500 points
Acquisition rate,
maximum
Up to 450 waveforms/s Up to 3,000 waveforms/s
Sample rate range
Acquisition res-
olution
TDS3012
TDS3014
TDS3032
TDS3034
TDS3052
TDS3054
Normal 100 S/s to
1 GS/s
100 S/s to
2.5 GS/s
100 S/s to
5 GS/s
Fast trigger 5 S/s to
1.25 GS/s
5 S/s to
2.5 GS/s
5 S/s to
5 GS/s
Seconds/division
range
— 4 ns/div to
10 s/div
2 ns/div to
10 s/div
1 ns/div to
10 s/div
n Sample rate and
delay time accuracy
±200 ppm over any ≥1 ms time interval
Trigger
External trigger input,
typical
1 M W in parallel with 17 pF, TekProbe compatible
(TDS3012, TDS3032, TDS3052 only)
External trigger
maximum voltage
Overvoltage category Maximum voltage
maximum voltage
CAT I Environment (refer to
page 1–11)
150 V
RMS
(400 V
pk
)
CAT II Environment (refer to
page 1–11)
100 V
RMS
(400 V
pk
)
For steady-state sinusoidal waveforms, derate at 20 dB/decade above
200 kHz to 13 V
pk
at 3 MHz and above.
External trigger maxi-
mum floating voltage
0 V from chassis (BNC) ground to earth ground
30 V
RMS
(42 V
pk
) only under these conditions: no signal voltages
>30 V
RMS
(>42 V
pk
), all common leads connected to the same voltage,
no grounded peripherals attached
n
Edge trigger
sensitivity
Source Sensitivity
sensitivity
Any channel, DC coupled 0.35 div from DC to 50 MHz,
increasing to 1 div at oscilloscope
bandwidth
Edge trigger
sensitivity, typical
Source Sensitivity
sensitivity, typical
External trigger 100 mV from DC to 50 MHz,
increasing to 500 mV at 300 MHz
External/10 trigger 500 mV from DC to 50 MHz,
increasing to 3 V at 300 MHz
