Tektronix TDS3034

Performance Verification
4–2
TDS3000 Series Service Manual
Test Record
Serial
number
Procedure performed by Date
Test Passed Failed
Self Test
Performance checks Low limit Test result High limit
Channel 1 DC
measurement
1 mV/div 99.25 mV 100.8 mV
measurement
accuracy
2 mV/div
–7.540 mV –6.460 mV
accuracy
5 mV/div –101.8 mV –98.24 mV
50 mV/div 982.4 mV 1.018 V
50 mV/div 632.4 mV 667.6 mV
50 mV delta 340.5 mV 359.5 mV
90 mV/div –339.3 mV –290.7 mV
200 mV/div 9.900 V 10.10 V
1 V/div –10.30 V –9.698 V
Channel 2 DC
measurement
1 mV/div 99.25 mV 100.8 mV
measurement
accuracy
2 mV/div
–7.540 mV –6.460 mV
accuracy
5 mV/div –101.8 mV –98.24 mV
50 mV/div 982.4 mV 1.018 V
50 mV/div 632.4 mV 667.6 mV
50 mV delta 340.5 mV 359.5 mV
90 mV/div –339.3 mV –290.7 mV
200 mV/div 9.900 V 10.10 V
1 V/div –10.30 V –9.698 V
